The EasyScan diagnostic and service tool has recently been updated to ensure compatibility with the newly introduced heaters and control units featuring CAN communication. EasyScan remains fully backward compatible, meaning that all previously supported heaters and control units will continue to be supported. The PC software has been expanded in the user interface to include the new products, while the proven overall structure remains unchanged.
Advantages:
- Comprehensive evaluation of current operating conditions
- Automatic saving of individual user settings, including migration during updates
- Fault analysis of devices and components
- Functional testing of heating applications
- Support during the initial commissioning of heating systems
- Integrated result logging for initial commissioning and diagnostic procedures
Compatibility:
Air and water heaters:
- Hydronic 1
- Hydronic 2
- Hydronic 2 Commercial
- Hydronic S3 Economy / Commercial
- Airtronic S2 / M2 Commercial / Recreational
Temperature Range:
-40°C to +70°C
Dimensions (L x W x H):
82 x 72 x 24 mm
Protection Class:
IP20
PC System Requirements:
- Standard PC or laptop with Windows 7
- Hardware: Minimum processor speed 1 GHz (depending on system configuration and data complexity)
- RAM: Minimum 1 GB (3 GB recommended)
- USB port
- Operating System: Windows 7 (32 & 64 Bit, SP1) or higher
- Languages: DE / EN / FR / IT / CZ / CN / JP / KO / RU
